Why You Need This Device :- It acts as a 24/7 smart guard for your 3-phase system, automatically detecting and preventing electrical faults like over/under voltage, current imbalance, and phase loss—protecting your appliances, avoiding costly damage, and ensuring uninterrupted power.
All-in-One :- With 3-phase energy monitoring, it provides over/under voltage, current, and frequency protection—plus phase-loss, phase-sequence, and imbalance protection.
Auto Reconnect Functionality :- Automatically restores power once parameters return to safe levels, reducing downtime and eliminating manual resets.
Real-Time Smart Monitoring :- Displays real-time voltage, current, power factor (PF), apparent power (VA), reactive power (VAR), frequency, active power, and total energy consumption (kWh)—ideal for energy audits, load balancing, and fault diagnostics.
Adjustable Delay Timers :- Customize power-on and recovery delays (1–999s) to prevent false triggers and protect connected appliances from unstable power spikes.
Easy & Secure Installation :- Designed for industrial and residential use with 35mm DIN rail mounting. Compact, durable, and built for long-term performance in demanding environments.
Warranty :-The products come with 1 year warranty (To claim warranty feel free to contact amicikart at 980-970-9898 or care@amicikart.com).

Technical Specification:

Rated Supply Voltage: AC 230V
High Measurement Accuracy: 0.5 Class
Max Load Capacity: Supports up to 80A
Adjustable Power-On Delay: 1s to 999s (Default: 30s)
Recovery Delay Time: 1s to 999s (Default: 30s)
Over-Voltage Protection: Adjustable 230V~300V (Default: 270V)
Over-Voltage Recovery: Adjustable 225V~295V (Default: 265V)
Under-Voltage Protection: Adjustable 140V~210V (Default: 170V)
Under-Voltage Recovery: Adjustable 175V~215V (Default: 175V)
Under-Voltage Action Time: 0.1s to 30s (Default: 0.5s)
Over-Current Protection: Adjustable 0.5A~80A (Default: ON)
No-Load Protection: Adjustable 1A~62A (Default: OFF)
Over-Current Recovery Delay: 1s to 500s (Default: 30s)
Frequency Over-Protection: Adjustable 60Hz~80Hz (Default: OFF)
Frequency Under-Protection: Adjustable 30Hz~50Hz (Default: OFF)
Frequency Action Time: 0.1s to 30s (Default: 5s)
Voltage Unbalance Protection (Three-Phase): 10V~100V (Default: ON)
Voltage Unbalance Recovery: 5V~45V (Default: 20V)
Current Unbalance Protection (Three-Phase): 2A~50A (Default: ON 20A)
Current Unbalance Action Time: 0.1s to 30s (Default: 0.5s)
Phase Sequence Protection: ON/OFF (Default: ON)
Over-Current Protection Limit: 1 to 20 Times (Default: ON)
Easy Installation: 35mm DIN Rail Mountable
