Wire Tester: -Check cable break point by tracing the cable with receiver and connecting another end with emitter. Sound tends to change where cable is broken.
2 in 1: -This tool can be used to trace cables that include telephone wires (RJ-11), computer network cable (RJ-45).
Feature: -High sensitivity and strong anti-jamming ability for identifying the target wire among bunch of wires.
With Earphone: -The device has a light on the top, which makes it convenient to use. Also, the volume can be adjusted, 3.5mm earphone jack is present for using earphones.
Package Include: -1 Year Warranty, 1 x Cable Emitter, 1 x Cable Receiver, 1 x Earphone, 1 x RJ45 Cable, 1 x RJ11 Cable, 1 x Cable with Crocodile Clamp, 1 x Instruction Manual.
1-Year Warranty & Dedicated Support : -For technical assistance or product support, reach out to us via WhatsApp, call, or email: 📞 980-970-9898 | ✉️ care@amicikart.com.

Feature:
Telephone wire, network cable and other electric wires scanning & finding
According to 16 wire sequences, you can judge the characteristics of short-circuit, breaking circuit, open circuit and crossing
Auto scan mode rapidly test corresponding double-twisted cables (1,2,3,4,5,6,7,8 and G) to judge wrong connection, short/open circuit
Network wire sequence collation supports direct wire collation of operating switch
Open, short and cross of LAN cable
2-wire (RJ11)/4-wire (RJ45) telephone cable
Line DC detecting, anode and cathode determination
Ringing signal detecting
Open, short, and cross test
High sensitivity & strong anti-jamming ability
Adjustable volume of signal
Auto time-delay power off
Low battery indication
Comes with RJ45 to BNC Converter
Trace telephone wire/ LAN cable
Trace wire in electrical system
Verify LAN cable condition
Cable Assignment Test: Open, short and cross of LAN cables, 2-wire (RJ11)/ 4-wire (RJ45) Telephone cable

Specifications:
The max working current: emitter: ?10mA; Receiver: ?30mA .
Signal output electric status: 8Vp-p .
Signal transmission format: multi-frequency impulse .
Distance of signal transmission: ?3km.
Power: DC 9V battery (Included)
Battery life: 50 hours continuously
Material: ABS plastic
Appearance dimension: 175*42*27mm(receiver); 126*49*34 (emitter).
Color: Orange (as shown in the picture)

Packages included:
1 x Cable Transmitter
1 x Cable Receiver/Tracker
1 x RJ45 Cable
1 x RJ11 Cable
1 x Cable with crocodile clamp
1 x Instruction manual
1 x Earphone
