Wide Input & Output Range: Converts 10V-32V DC input to 45V-390V DC output, with a peak power of 70W, ideal for high-voltage applications like capacitor charging.
Efficient Power Conversion: ZVS technology offers up to 88% efficiency, ensuring stable and low-heat operation, even under varying input/output conditions.
Wide Application Range: Ideal for powering LED strips, CCTV cameras, audio equipment, and other electronic projects requiring 24V DC input.
Built-in Safety Protections: Features overcurrent, overvoltage, and short circuit protection with a 10A fuse for reverse polarity safety.
Reliable & Durable: Operates from -40°C to +85°C with a compact, robust design for integration into DIY electronics, battery charging, and solar systems.
Warranty:- The products come with 1 year warranty (To claim warranty feel free to contact amicikart at 980 970 9898 or care@amicikart.com)

Specifications:-
Input Voltage: 10V-32VDC
Input current: 5A (MAX)
Output voltage: 45-390VDC
Output power: 40W (peak 70W)
Output current: 0.2A MAX (affected by input voltage and voltage difference, the higher the output voltage, the smaller the output current)
Working temperature: -40 ℃~+85 ℃ (if the temperature is too high, please strengthen heat dissipation)
Operating frequency: 75KHz
Conversion efficiency: up to 88% (affected by input voltage, output voltage, current, and voltage difference)
Short circuit protection: Yes. (Input 10A fuse, please do not short-circuit the arc at the output end, otherwise it may damage electronic components. If necessary, please add a series power resistor to limit it)
Overcurrent protection: Yes. (If the input current exceeds 4.5A, reduce the output voltage)
Overvoltage protection: Yes (if the output voltage exceeds 410V, reduce the output voltage)
Input reverse polarity protection: Yes (Non self-healing, reverse burning fuse, you'd better not reverse it.)
