Battery Pack Spot Welder :- Well, most people regularly struggle while making battery packs with normal soldering iron, so here we present our new product i.e. amiciTools Spot Welder, in no time you can create multiple battery packs and save your time.
Adjustable Current :- One of the main features of this spot welder is you can adjust the current according to your welding requirements, with the fast-heating speed and high power up to 5000W a maximum of 0.15mm nickel strip can be welded.
Upgraded Digital Tube Display :- Our DIY spot welder is designed with a digital tube display, through which you can clearly check the remaining battery, make your spot-welding journey easier and safer.
Wide Applications :- This mini spot welder is mainly used in the welding of nickel sheets of battery, which can be used for spot-welding cylindrical lithium batteries such as 18650/21650 and etc., nickel metal hydride/ cadmium nickel batteries can be welded firmly.
Built-in Safety Protection :- Well, you don’t need to worry now while using our spot-welder it owns perfect over charge, over temperature protection functions. Its unique overheating protection device automatically cuts off power when the overheating occurs which makes it safer to use.
Flexible Welding Pen :- The 35cm gold-plate spot-welding pen consists of multiple strands of high temperature wire with fine torsional resistance ability, making the operation more flexible.
1-Year Warranty & Dedicated Support :- For technical assistance or product support, reach out to us via WhatsApp, call, or email: 📞 980-970-9898 | ✉️ care@amicikart.com.

Our DIY spot welding machine with fine workmanship, stable performance and long service life provides you an easy solution for spot-welding, with fine conductivity and low contact resistance. This mini spot welder is mainly used in the welding of nickel sheets of battery, which can be used for spot-welding cylindrical lithium batteries such as 18650/21650 and etc., nickel metal hydride/ cadmium nickel batteries can be welded firmly.

Specification:-

Item Type: Spot Welding Machine
Material: ABS brass
Wield Thickness: 0.1-0.15mm
Output Power: 5000W
Battery: 4000mah

Note:

1. The displayed number is the battery voltage, the knob remains unchanged, and the knob is used to adjust the current
2. Welding 0.1mm, the current is set to 5, welding 0.15mm, the current is adjusted to 6 positions, welding 0.2mm, the current is adjusted to 8 positions.

How to Use:
1. When the upper of the welding nail becomes black, sand it with fine sandpaper.
2. Press the nickel tape with two soldering pens and step on the foot switch.
3. Wait about 0.5 seconds for output spot welding, and then release the foot switch.
4. Do not use the voltage below 7.3V, please charge in time.

Package List:

1 x Welding Machine Host 1 x Adapter 1 x Iron Sheet 1 x Matte Paper
